Compact C-Frame Servo Press
High-speed, open-access press fitting system for small electronic components, sensors, and micro bearings.
Capacity: 1-10 Tons · Stroke: 150mm · ±0.01mm Precision
SERVO PRESS TECHNOLOGY · RUNWIND
Servo Driven Hydraulic Press Machine for High Precision Press-Fitting & Stamping
Runwind servo driven hydraulic presses integrate closed-loop servo motor control, real-time force-displacement monitoring, ±0.01mm positional accuracy, and up to 60% energy savings for automotive parts, motor stators, bearing assembly, and precision metal forming operations.
±0.01mm Repeatability
Real-Time Displacement Curve
MANUFACTURING CONFIDENCE
Engineered for Continuous Industrial Stamping and Zero-Defect Press Fitting
Every Runwind servo hydraulic press features a heavy-duty steel frame, closed-loop pressure sensors, and intuitive touchscreen PLC controls. Operators can program multi-stage pressing speed, pressure holding time, and quality control evaluation boundaries on the fly.
±0.01 mm
Positioning repeatability
60% Energy
Lower power consumption
100% FAT
Pre-shipment force curve test
EQUIPMENT FLEET
Servo Driven Hydraulic Press Machine Configurations
Four-Column Heavy Duty Servo Press
Rigid 4-column guidance structure for auto body stamping, composite molding, and deep drawing applications.
Capacity: 20-200 Tons · Real-time Force Curve · PLC Control
Automated Gantry Servo Press Line
Integrated robotic gantry servo press line with automatic die change and Industry 4.0 data logging.
Capacity: 50-500 Tons · Robotic Loading · Full Traceability
INDUSTRIAL SPECIFICATIONS
Servo Driven Hydraulic Press System Specifications
| Parameter / Feature | Compact C-Frame | Four-Column Heavy Duty | Automated Gantry Line |
|---|---|---|---|
| Nominal Pressing Force (kN/Tons) | 10 - 100 kN (1-10 T) | 200 - 2,000 kN (20-200 T) | 500 - 5,000 kN (50-500 T) |
| Positional Repeatability (mm) | ±0.01 mm | ±0.01 mm | ±0.01 mm |
| Ram Stroke Distance (mm) | 150 mm | 300 - 500 mm | 400 - 800 mm |
| Energy Consumption vs Standard Hydraulic | -55% Energy Saved | -60% Energy Saved | -65% Energy Saved |
| Control & Data System | 7 Inch PLC Touchscreen | 10 Inch PLC + Curve Export | 15 Inch Industrial PC + MES |
Ready to Upgrade Your Factory Press Precision with Servo Control?
Contact Runwind engineering team today to evaluate force requirements, stroke speed, tooling integration, and get a custom quote within 24 hours.
